Features
• Digital transmission over long distances due to DMX- and AES/EBU-Standards
• Very good protection against electrical interference (copper braiding + AL/PT-foil)
• Extremely robust due to the special tough jacket
Applications
• Development and fast wiring of prototypes
• Fixed installation in dry and closed buildings
• Interior wiring for electrical units
Cable Colour
• Black
Technical Data
|
|
Jacket, diameter
|
PVC 7.0 mm
|
AWG
|
22
|
No. of inner conductors
|
4 x 0.34 mm²
|
Copper strand per conductor
|
7 x 0.25 mm
|
Conductor insulation
|
PE 1.70 mm
|
Shielding
|
Tin plated copper braided shielding
with 128 x 0.10 mm
+ AL/PT-foil
|
Shielding factor
|
100 %
|
Temperature range
|
min. -20 °C
|
Temperature range
|
max. +70 °C
|
Packaging
|
100/300 m roll
|
|
|
Electrical Data
|
|
Capac. cond./cond. per 1 m
|
49.7 pF
|
Capac. cond./shield. per 1 m
|
108.7 pF
|
Cond. resistance per 1 m
|
52.9 mΩ
|
Shield. resistance per 1 m
|
22.59 mΩ
|
