GC040
Instrument cable - 24AWG - 1 x 0.24mm²

Features

• Very robust due to the large conductor diameter and fine individual stranding

• 100 % protected due to double shielding (dense copper braided + semiconductor shielding)

• High durability due to a thick PVC jacket with a diameter of 7.0mm

• High flexibility makes it easy to wind


Applications

• High quality guitar cable for studio and stage

• Unbalanced cable for keyboards, samplers, mixing boards, etc


Cable Colour

• Black

• Blue


Technical Data

Jacket, diameter
PVC 7.0 mm
AWG
24
No. of inner conductors
1 x 0.24 mm²
Copper strand per conductor
30 x 0.10 mm
Conductor insulation
PE 1.95 mm
Shielding

copper braided shielding

with 128 x 0.10 m

+ semiconductor

Shielding factor
100 %
Temperature range
min.-20 °C
Temperature range
max.70 °C
Packaging
100/300 m roll


Electrical Data

Capac. cond./shield. per 1 m
88 pF
Cond. resistance per 1 km
85 Ω
Insulation resist. per 1 km
> 1 GΩ



Packaging

Wooden drum packaging


Carton drum packaging


Plastic drum packaging


Film packaging
