Features
• Unique design lockable 3 pin equipment(AC)connector, ideal for LED screen, lighting and other equipments
• Dust and water resistant according to IP65 in mated condition
• Fast and easy twist lock system
• Flame retardant materials create safer use
• Glass fiber composite material, extremely robust and reliable
• ROXTONE brand engraved ont the shell
• Patent protected
Available Color Rings
Technical Data
|
|
Housing
|
PA66 30% GR
|
Insert
|
PA66 30% GR
|
Latch
|
Zinc Alloy diecast
|
Unitary contacts
|
Bronze
|
Contacts plating
|
Silver
|
|
Strain relief
|
POM
|
Sealing bushing
|
Silicone
|
|
Color ring
|
PA6
|
Number of contacts
|
3
|
Rated current per contact
|
20 A rms
|
Rate voltage
|
250 V ac
|
Cable O.D. range
|
6-12 mm
|
Protection class(mated)
|
IP65
|
Fammability
|
UL V-0
|
Engineering Drawing
Application & Assembly Instruction
DOWNLOAD
