Features
• The special double strands technology with very thin OFC wires ensure the cable to be super highly flexible
• Soft PVC jacket and inner conductors twisted grant a perfect winding
Applications
• Professional PA/sound systems
• Surround and woofer systems
• For fixed installation in building technology
Cable Colour
• Black
• Blue
Technical Data
|
|
Jacket, diameter
|
PVC 12.0 mm
|
AWG
|
14
|
No. of inner conductors
|
4 x 2.5 mm²
|
Copper strand per conductor
|
318 x 0.10 mm
|
Cond. PVC insulation, diameter
|
3.4 mm
|
Temperature range
|
min. -20 °C
|
Temperature range
|
max. +70 °C
|
Packaging
|
100/300 m roll
|
|
|
Electrical Data
|
|
Capac. cond./cond. per 1 m
|
100 pF
|
Cond. resistance per 1 m
|
6.8 mΩ
|
|
|
