Features
• Super flexible, drag chain test performance more than 20,000 times
• Flame retardant & Cold –resistant
• Suitabe for stage mobile use
Cable Colour
• Black
Technical Data
|
|
|
|
Order Code
|
HFPC315
|
HFPC325
|
PVC Jacket, diameter
|
PVC 8.3 mm
|
PVC 10.2 mm
|
AWG
|
16
|
14
|
No. of inner conductors
|
3 x 1.50 mm²
|
3 x 2.50 mm²
|
Conductor insulation
|
PVC 3.25 mm
|
PVC 3.25 mm
|
Temperature range
|
min. -20 °C
|
min. -20 °C
|
Temperature range
|
max. +80 °C
|
max. +80 °C
|
Packaging
|
100 m roll
|
100 m roll
|
|
|
|
Technical Data
|
|
|
Rated voltage
|
300/500 V
|
300/500 V
|
Test voltage
|
2000 V
|
2000 V
|
Test time
|
1 min
|
1 min
|
Insulat.resistance
|
≥5 MΩ
|
≥5 MΩ
|
